5kW Hybrid Solar Power Plant PM Surya Ghar Muft Bijli Yojana

About 5kW Hybrid Solar Power Plant PM Surya Ghar Muft Bijli Yojana

5kW Hybrid Solar Power Plant under PM Surya Ghar Muft Bijli Yojana is a high-performance solar solution designed for homes, shops, and small commercial setups.

It combines solar panels, hybrid inverter, and optional battery storage to ensure continuous power supply, reduced electricity bills, and energy independence.

Ideal for Indian conditions, this system supports net metering and government subsidy, making it a cost-effective and future-ready investment.

Key Features

• Hybrid system (Solar + Battery + Grid)
• Power backup during electricity cuts
• Net metering enabled (export excess power)
• Smart automatic switching system
• WiFi-enabled mobile monitoring
• Subsidy applicable (PM Surya Ghar Scheme)
• Expandable up to 10kW

Technical Specifications

General Specifications

• Product Type: Hybrid Solar Power Plant
• Capacity: 5kW
• Technology: Mono PERC / TOPCon
• Installation Type: Rooftop / Ground Mounted
• Application: Residential, Shops, Offices

Electrical Specifications

• Output Voltage: 230V AC (Single Phase) (corrected)
• Input Voltage (DC): 350V 600V
• Max System Voltage: 1000V DC
• Efficiency: 97% 98%
• Inverter Type: Hybrid (Battery Compatible)

Performance & Environment

• Operating Temperature: -10C to +55C
• Protection: IP65 Rated Inverter
• Panel Warranty: 25 Years

Physical Specifications

• Panel Size: 2000 1000 mm
• Total Area Required: 300 350 sq. ft. (corrected)
• Structure Material: Hot Dip GI / Aluminum
• Panel Material: Tempered Glass + EVA + Backsheet
• Weight: Approx. 450 650 Kg (corrected)

Module Details

• Cell Type: 144 Half-Cut Cells
• Module Wattage: 540W 550W
